| Paremeter | |
| CPU | RK3288 |
| Frequency | 2.2 GHz |
| RAM | DDR3 2G/4G optional |
| EMMC | EMMC 8GB/16G/32G optional(standard 8GB,support NAND FLASH) |
| Interface of monitor | LVDS(single way,6 bit two-way,8 bit two-way).Resolution max 1920x1080,support 7"-84" monitar |
| EDP 2.0, Resolution max:support 2K screen | |
| Mainboard backlight | Support 3.3V/5V/12V(optional) |
| Touch Screen | I2C interface(support resistive touch, capacitive touch) Support USB IR multi touch,sonic multi touch,optical multi touch |
| Network | RJ45 interface, ethernet 10/100/1000M |
| Wi-Fi 802.11b/g/n/ ac, BT4.0 | |
| Image rotation | Support 0°, 90°, 180°, 270°, manual control or automatic, gravity |
| RTC | internal battery for Real time clock |
| Interfaces |
Support MIPI camera,max 5MP |
| Support USB camera, max 2MP | |
| USB HOST x 5,USB OTG x 1 | |
| Serial ports x 3, support external devices(NFC module, printer, card reader etc.). | |
| IO ports x 3 | |
| TF card slot, support 32GB max | |
| D amplifier:3W*2 8Ω,support microphone | |
| 2.0 | |
| Audio | MP3,WMA,WAV, APE, FLAC, AAC, OGG,M4A,3GPP |
| Video | Support H.264,MPEG2,VP6,VP8,MVC, 2160P@24FPS decoding, . on-line video such as YouTube, max support 1080P,HTML5 playback,Flash10.1 playback |
| Picture | Support JPG,BMP,PNG etc. picture formats, browse, orientation, slides, magnify |
| Power supply | input:AC100-240V.50-60HZ, output: DC12V 3A |
