| Parameter | |
| Main Control Chipset (DSP) | V57 |
| Image Sensor Interface | MIPI |
| Battery Voltage | 7.4V - 7.7V High Voltage Lithium Battery |
| Storage Type | External TF Card, Supports 8GB - 512GB Class 10 and Above, U3 is Recommended |
| Type-C Port | Type-C USB 5V Connection to Computer USB Mode Connection to PCCAM (Camera) Mode Type-C 2.0 Interface, Type-C 3.0 Interface |
| LED Indicator Type | Three Color Light (Red, Green, Blue) |
| 2 Control Button Type | Power Button (A), OK Button (B) |
| Power Supply | Supports 3 Power Supply Methods At The Same Time (1) 5V USB to Type-C Port Power Supply (2) 9V-24V WiFi Board Power Supply (3) 6.8V-8.4V Battery Power Supply |
| Operating Temperature | -10°C to +60°C Without Housing |
| Storage Temperature | -20°C to +80°C |
| Humidity | 20% to 80% |
| PCB Dimensions | 38 x 38 mm |
| PCB Screw Hole Spacing | External (34mm x4), Internal (28mm x2) |
| PCB Screw Hole Diameter | 2 mm |
| Optional Camera Configuration | (1) KLT-G5M7 V2.0 + Camera (2) KLT-G5M7 V2.0 + Camera + KLT-G1WF V6.3 WiFi Board |
| Supportive Image Sensors | 48MP: IMX586 12MP: IMX577 |
| Optional Extension Ports | WiFi, Camera Module, UART, I2C, SPI, IO etc. |
| Video Resolution | 4K@24/25/30/FPS 2.7K@24/25/30/48/50/60FPS 1080P@24/25/30/48/50/60/120FPS 720P@24/25/30/48/50/60/120/240FPS |
| Photo Resolution | 48MP (8000x6000) 14MP (4592x3056) 12MP (4000x3000) 10MP (3648x2736) 8MP (3264x2448) 5MP (2592x1944) 3MP (2048x1536) 2MP (1920x1080) |
